1TS-140W - Active Vibration Isolation Workstation
Standa
9.999,99 €
Versandfertig in 1 Tag, Lieferzeit 1-2 days
Produktnummer:
644616589
Produktinformationen "1TS-140W - Active Vibration Isolation Workstation"
Isolation: dynamic 0.7 Hz to 200 Hz, mainly passive at higher frequencies, although for good stability the feedback is active to at least 2 KHz
Transmissibility: See curve. Above 10 Hz transmissibility <0.01 (-40dB)
Maximum load: 140 kg
Working surface: 500x600 mm
Self - weight: 23 kg
Electrical
Safety class: 1
Power consumption: maximum 10 W when isolating, maximum 20W during load adjustment
Input voltage: 90 – 120V AC, 47 – 63 Hz / 200 – 240V AC, 47 – 63 Hz
Fuses: 2x1.6A/250V slow, located in the power socket on the rear side of the unit
Normal Environmental Conditions
Protection class: IP 20
Temperature range: 5°C - 40°C
Relative Humidity: 10 - 90% (5 - 30°C) / 10 - 60% (30 - 40°C)
Application: Indoor
Altitude: Up to 2000 m (6.500 ft)
Transmissibility: See curve. Above 10 Hz transmissibility <0.01 (-40dB)
Maximum load: 140 kg
Working surface: 500x600 mm
Self - weight: 23 kg
Electrical
Safety class: 1
Power consumption: maximum 10 W when isolating, maximum 20W during load adjustment
Input voltage: 90 – 120V AC, 47 – 63 Hz / 200 – 240V AC, 47 – 63 Hz
Fuses: 2x1.6A/250V slow, located in the power socket on the rear side of the unit
Normal Environmental Conditions
Protection class: IP 20
Temperature range: 5°C - 40°C
Relative Humidity: 10 - 90% (5 - 30°C) / 10 - 60% (30 - 40°C)
Application: Indoor
Altitude: Up to 2000 m (6.500 ft)
